ALCO Emerson TS1-A2A Temperature Control Switch, -30 to +15°C Range, 2m Capillary Bulb, SPDT, Adjustable Differential, IP44, Original Anti-Freeze Switch for HVAC & Chillers

ALCO Emerson TS1-A2A Temperature Control Switch, -30 to +15°C Range, 2m Capillary Bulb, SPDT, Adjustable Differential, IP44, Original Anti-Freeze Switch for HVAC & Chillers

The ALCO Emerson TS1-A2A is an original, high-precision temperature control switch engineered for critical applications in HVAC systems, cold storage units, and chillers, particularly for anti-freeze protection. This robust thermostat features an adjustable temperature range of -30 to +15°C and a 2-meter capillary tube with a temperature bulb for accurate remote sensing. Designed for reliability, the TS1-A2A offers chatter-resistant SPDT (Single Pole Double Throw) contacts with high operational and locked rotor current ratings, ensuring stable and safe control of refrigeration and air conditioning circuits. Its durable construction and IP44 protection (without off-switch) make it suitable for various industrial environments.

Manufacturer Information:

• Manufacturer: Emerson (formerly ALCO Controls)
• Part Number (Model): TS1-A2A
• Product Family: Pressure Controls & Thermostats
• Product Type: Temperature Control Switch / Thermostat (specifically known as an Anti-Freeze Switch in certain applications due to its low-temperature range)
• Function: Adjustable thermostat - automatic reset
• Key Specifications:
  • Temperature Range: -30 to +15 °C
  • Differential Range: 1.5 to 16 K (Kelvin, equivalent to °C for differential)
  • Temperature Sensor: 2 m capillary and bulb
  • Bulb Temperature - Max: 150 °C (Refers to the maximum temperature the sensor bulb can withstand)
  • Contacts: Standard SPDT (Single Pole Double Throw)
  • Operational Current: High, specified as Locked Rotor Max. 144 A (LRA) across both contacts, indicating robust switching capacity.
• Features:
  • Adjustable Temperatures and Differentials: Allows precise tuning to specific system requirements.
  • Chatter Resistant Contacts (Bounce-Free): Ensures reliable switching and extends contact life.
  • High Operational Current Capacity: Capable of directly switching motors or other high-load components, including those with high inrush (locked rotor) currents.
  • Same Operational Current Rating for Both SPDT Contacts: Provides consistent performance regardless of contact state.
  • Captive Terminal and Cover Screws: Facilitates easier installation and prevents loss of hardware.
  • Range and Differential Individually Lockable by Wire Seal: Enhances tamper-proofing and maintains set parameters.
  • IP Rating: IP44 (without off-switch), IP30 (with off-switch), providing protection against solid objects and splashed water (IP44).
  • Ambient Temperature Range: -50 to +70°C, suitable for a wide variety of environmental conditions.
  • Marking: CE (indicates conformity with European health, safety, and environmental protection standards).
• Application: Ideal for temperature control and anti-freeze protection in:
  • Air Conditioning Units: Preventing coil freeze-up.
  • Cold Storage / Refrigeration Systems: Maintaining precise temperature within cold rooms and freezers.
  • Chillers and Cooling Towers: Safeguarding against freezing in water circuits.
  • Industrial Refrigeration: Various cold chain and processing applications.
  • Heat Pumps: Temperature monitoring and control.
• Batteries Included: No (This typically confirms it is a hard-wired electro-mechanical control).
