ABB AX25-30-10 3Pole Contactor (2 Pieces)

Brand: ABB
Product Name: Contactor
Catalog Number: AX25-30-10-81
Product ID: 1SBL931074R8110
EAN: 3471522397812

Overview

The ABB AX25-30-10-81 Contactor is a robust, block type contactor specifically designed for the reliable control of 3-phase motors and power circuits operating up to 690 V AC. Part of the proven AX09 to AX25 series, this contactor is engineered to meet the demands of various industrial and commercial applications. It features a compact block design, incorporating 3 main poles and 1 built-in normally open (NO) auxiliary contact, providing essential functionality for control and feedback systems. The control circuit is AC operated, with a versatile 24V AC (50/60Hz) coil, making it ideal for systems requiring low voltage control. Its design allows for enhanced flexibility through the addition of auxiliary contact blocks, which can be mounted on the front or side to expand control capabilities.

Key Features

• 3 Main Poles: Optimized for efficient switching and control of 3-phase AC loads, particularly electric motors.
• Integrated Auxiliary Contact: Includes 1 built-in normally open (NO) auxiliary contact, simplifying wiring for control circuits and status indication.
• High Voltage Capability: Suitable for power circuits operating up to 690 V AC, ensuring broad application versatility.
• AC Operated Coil: Features a 24V AC (50/60Hz) control voltage, ideal for low-voltage control systems and compatible with global power frequencies.
• Block Type Design: Offers a compact and sturdy construction for dependable operation in demanding industrial environments.
• Expandable Auxiliary Contacts: Supports the addition of front or side-mountable auxiliary contact blocks, allowing for flexible configuration of control and signaling circuits.
• ABB Quality & Reliability: Manufactured by ABB, a globally recognized leader in electrification products, ensuring high standards of performance, safety, and durability.
