ABB 1SAM150000R1007 MS325-2.5 Manual Motor Starter, 2.5 A, 100 kA, IP20 - Pack of 1

Overview

The MS325-2.5 manual motor starter is a 54 mm width device with a rated operational current of Ie = 2.5 A. It is used to manually switch on and off motors and to protect them reliably from short-circuits, overload, and phase failures without the need for a fuse. The starter offers a rated service short-circuit breaking capacity Ics = 100 kA at 400 VAC and trip class 10A. Features include a disconnect function, temperature compensation, a trip-free mechanism, and a rotary handle with clear switch position indication, suitable for three- and single-phase applications.

Key Features

• Rated Operational Current: 2.5 A
• Rated Service Short-Circuit Breaking Capacity: 100 kA at 400 VAC
• Trip Class: 10A
• Disconnect Function
• Temperature Compensation
• Rotary Handle with Clear Switch Position Indication

Specifications
