Schneider Electric BMXXBP0800 Modicon X80 Backplane — 8‑Slot Rack (Processor/I/O/Comm), Panel/Plate/DIN‑Rail Mountable, IP20

Product overview The Schneider Electric BMXXBP0800 is an 8‑slot backplane designed for the Modicon X80 family. It provides the mechanical and electrical backbone for processors, I/O, communication and application‑specific modules (excluding power supply), supporting M340/M580 compatible modules and enabling hot‑swappable I/O for simplified maintenance and modernization.

Key specifications

• Manufacturer: Schneider Electric
• Model: BMXXBP0800 (Modicon X80 backplane)
• Product type: Backplane / rack (8 slots)
• Number of slots: 8 (bus X) — accommodates processor, I/O, communication and application modules; power supply module excluded
• Compatibility: Modicon X80 modules; compatible with BMXP34 processors, BMXCPS power supplies, standard I/O and application modules in X80 family; compatible with Modicon M340/M580 module ecosystem where specified
• Mounting / fixing options:
  • Panel mounting: by 4 × M4 / M5 / M6 screws
  • Mounting plate: by 4 × M4 / M5 / M6 screws
  • DIN‑rail: clips for 35 mm symmetrical DIN rail
• Electrical connection: 1 connector (XBE) for expansion modules
• Power consumption: 2.21 W (backplane only)
• Mechanical dimensions:
  • Height: 103.7 mm
  • Width: 372.8 mm
  • Depth: 19 mm
  • Net weight: 0.95 kg
• Environmental & protection:
  • IP degree of protection: IP20
  • Operating ambient temperature: 0…60 °C
  • Relative humidity: 10…95 % without condensation
• Features:
  • Stable in‑rack module mounting with hot‑swap capability for most I/O modules (reduces downtime)
  • Common backplane for Modicon M340, M580 and X80 modules for easier modernization and spare parts consolidation
• Standards & certifications:
  • CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy
  • Standards: EN/IEC 61131‑2, EN/IEC 61010‑2‑201, UL 61010‑2‑201, CSA C22.2 No 61010‑2‑201, IACS E10, EN/IEC 61000‑6‑5 (interface type 1 & 2), EN/IEC 61850‑3 (location G)
• Packaging & warranty:
  • Packaging units and weights per Schneider Electric documentation
  • Contractual warranty: 18 months

Applications & benefits

• Use as the base rack for Modicon X80 distributed I/O systems in process, machine and infrastructure automation.
• Enables hot‑swap I/O replacement to minimize downtime and simplify field maintenance.
• Multiple mounting options (panel, mounting plate, DIN‑rail) make the backplane suitable for control panels, skids and modular assemblies.
• Common platform compatibility supports phased modernization from legacy Modicon systems with reduced training and spare parts complexity.

Installation notes

• Install using recommended screws or DIN‑rail clips per mechanical mounting option selected.
• Ensure correct insertion order and seating of processor, I/O and expansion modules; observe manufacturer guidance for power supply installation (power supply module is not included in the backplane slots).
• Observe ambient temperature and humidity limits and install in IP20‑rated enclosures.
• Use provided XBE connector for expansion connections per Schneider Electric wiring diagrams.

Documentation

• Product datasheet, user guide, instruction sheet and CAD files available from Schneider Electric support portal.
