OMRON NS12-TS00B-V2-932 NS Series Programmable Terminal, 12.1-inch TFT Color LCD, 800x600 SVGA, Black Case

The OMRON NS12-TS00B-V2-932 is a high-performance 12.1-inch Human Machine Interface (HMI) designed for large-scale industrial visualization and control. Part of the advanced NS-series, this model features a bright TFT color LCD with 32,768 colors and an SVGA resolution of 800 x 600 pixels, providing a high-density display area for complex process monitoring. The "V2" hardware revision indicates an upgraded processor for faster screen switching and improved system response, while the "932" designation refers to high-capacity internal system configurations tailored for global industrial standards.

Housed in a sleek black chassis, this terminal offers extensive connectivity, including two RS-232C serial ports for direct PLC interfacing and a USB Slave port for rapid project transfers. It is equipped with 60 MB of internal memory to support high-resolution graphics and intensive data objects. Expansion is simplified through a dedicated slot for Ethernet or Controller Link modules, alongside a standard CompactFlash slot for recipe data, alarm history, and screen backups. The front panel is IP65 rated, ensuring the unit thrives in harsh manufacturing environments.
