TDK Electronics B32361A2506J050 B3236X FilterCap MKP AC Single-Phase Capacitor, 250V AC (VRMS) / 350V AC (VR), 50µF, M6 Terminals, 63.5×70mm - Pack of 3
Regular price
$200.00 USD
Regular price
Sale price
$200.00 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Secure checkout via Credit Cards, PayPal & Bank Wire (T/T)
Overview
TDK Electronics B32361A2506J050 is a FilterCap MKP AC – Single phase capacitor from the B3236X series. It uses metallized polypropylene film with self-healing technology and an overpressure disconnector in an aluminum can, ideal for general-purpose AC filtering in power electronic converters. Sold as a pack of 3.
Key Features
- Metallized polypropylene film; resin filled (non‑PCB), IP00
- Overpressure disconnector safety device; self‑healing
- Naturally air‑cooled (forced air optional)
- Complies with IEC 61071; UL 810 approval file E106388; RoHS; CE
- M6 screw terminals; bottom stud mounting/grounding
Applications
- Single‑phase AC filtering in rectifiers/inverters and general power electronics
Specifications
| Specific MPN | B32361A2506J050 |
| Series / Type | B3236X FilterCap MKP AC – Single phase (B32361, M6 screw terminals) |
| Capacitance (CR) | 50 µF ±5% (J) |
| Rated AC Voltage (VR) / VRMS | 350 V (line‑to‑line peak) / 250 V AC (line‑to‑line RMS) |
| Rated DC Voltage (VRDC) | 675 V DC |
| Maximum RMS Current (Imax) | 25 A (terminal limit for B32361: 25 A) |
| Peak Current (Î) | 1250 A |
| Surge Current (Is) | 3.8 kA (max, non‑repetitive) |
| Series Resistance (Rs) | 3.7 mΩ (20°C) |
| Self‑inductance (Lself) | 195 nH |
| Terminals | M6 screw terminals (B32361) |
| Dimensions (D × H) | 63.5 mm × 70 mm (aluminum can) |
| Weight | ≈0.3 kg |
| Operating Temperatures | Ambient −40°C to +70°C; hot‑spot up to +85°C |
| Standards / Compliance | IEC 61071; UL 810 (File E106388); GB/T 17702; RoHS; CE |
| Pack Size | 3 pieces |
